隨著醫療新技術和新的手術工具的不斷涌現，帶動了手術量的迅猛上升，而且手術室是醫學技術與工程技術結合的產物，下面來講講
手術室建設要求以及
手術室感染控制原則是怎樣的？
With the continuous emergence of new medical technologies and new surgical tools, the number of operations has increased rapidly. Moreover, the operating room is the product of the combination of medical technology and engineering technology. What are the requirements of the operating room and the principles of infection control in the operating room?
手術室的要求
Operating room requirements
手術室是醫院中無菌潔凈要求很嚴格的地方之一，手術室的建設、布局、工作流程和治理都是圍繞無菌要求設計的。
The operating room is one of the places in the hospital with strict aseptic and clean requirements. The construction, layout, work flow and management of the operating room are designed around the aseptic requirements.
手術室又是醫療設備密集的科室，
除手術床、無影燈外，麻醉機、監護、電刀以及自體血回收機、
手術顯微鏡、影像系統等已成為手術常用設備。隨著技術的發展，新的手術工具不斷涌現，如各類軟硬內窺鏡下手術、導航設備、立體定位系統、手術機器人等微創手術輔助設備等，如此眾多的設備擁擠在手術室內，對設備布局、安裝、配電及用電安全提出了更高的要求。
The operating room is also a department with dense medical equipment. In addition to the operating table and shadowless lamp, anesthesia machine, monitoring, electric knife, autologous blood recovery machine, operating microscope and imaging system have become common equipment for surgery. With the development of technology, new surgical tools are constantly emerging, such as various soft and hard endoscopic surgery, navigation equipment, stereo positioning system, surgical robot and other minimally invasive surgical auxiliary equipment. So many equipment are crowded in the operating room, which puts forward higher requirements for equipment layout, installation, power distribution and power safety.
另外，現在各家醫院分散建設的導管室、膀胱鏡室等，有些也是參照手術室要求建立起來的準手術室。尤其是開展參與治療的導管室，基本上是嚴格按照手術室的規范治理和使用，這些科室廣義上說也是擴展的手術室。這些準手術室在老醫院都是見縫插針式地建設，新建醫院應該綜合考慮這些科室與常規手術室間的布局安排。
In addition, some of the catheter rooms and cystoscopy rooms scattered in various hospitals are also quasi operating rooms established according to the requirements of operating rooms. In particular, the catheter rooms involved in the treatment are basically managed and used in strict accordance with the specifications of the operating room. In a broad sense, these departments are also expanded operating rooms. These quasi operating rooms are built in the old hospital in a timely manner. The new hospital should comprehensively consider the layout between these departments and the conventional operating rooms.
Principles of infection control in operating room
防止和降低手術感染是手術室建設很基本的要求，感染控制的方法有：
Preventing and reducing surgical infection is a very basic requirement for the construction of the operating room. The methods of infection control include:
(1)通過術前備皮和術中對非手術區域的無菌覆蓋，減少患者自身感染；(2)對手術用具和物品的嚴格消毒或隔離，減少外源接觸感染；(3)降低空氣中的灰塵和微生物粒子，減少懸浮污染物的擴散感染；(4)使用抗生素。這是一種補救措施，其靠藥物往控制已發生的感染。
(1) Through preoperative skin preparation and aseptic coverage of non-surgical areas during the operation, the patient's self infection can be reduced; (2) Strictly disinfect or isolate surgical instruments and articles to reduce external contact infection; (3) Reduce the dust and microbial particles in the air and reduce the diffusion and infection of suspended pollutants; (4) Use antibiotics. This is a remedial measure that relies on drugs to control the infection that has occurred.
我國目前普遍存在的題目是，只注重預防感染結果，而忽略了對感染的全過程控制。臨床表現是依靠大量抗生素來減少術后感染率，而對手術無菌過程缺乏嚴格控制。
At present, the common problem in our country is that we only pay attention to the prevention of infection results and neglect the whole process control of infection. The clinical manifestation is to rely on a large number of antibiotics to reduce the postoperative infection rate, while the aseptic process of the operation lacks strict control.
為減少抗生素的濫用，必須進步手術室潔凈水平，嚴格無菌操縱和治理，加強對整個手術過程的控制，切斷所有可能的污染途徑(包括空氣)，阻止細菌接觸手術創口進進人體。
In order to reduce the abuse of antibiotics, it is necessary to improve the cleanliness level of the operating room, strictly control the aseptic operation and treatment, strengthen the control of the whole operation process, cut off all possible pollution channels (including air), and prevent bacteria from contacting the surgical wound and entering the human body.
大顆粒
氣溶膠發生器(氯化鉀發生器)
型號：DLY-8108
產生直徑高達10μm的高濃度氣溶膠顆粒
DLY-8108型大顆粒氣溶膠發生器（氯化鉀發生器）能夠產生直徑為0.1至10微米的高濃度鹽氣溶膠，滿足已制定的ISO/TS 11155-1和ASHRAE 52.2測試規范以及建議的ISO 16890第2部分規范的要求。
使用氯化鉀（KCl）生產試驗氣溶膠。DLY-8108型產生、干燥和靜電中和氣溶膠，以確保在日積月累使用條件下、可重復結果的準確性。
應用范圍
+ 氣溶膠生成
+ 過濾器測試
+ 產生適用于汽車座艙和通風空氣過濾器測試、真空吸塵器性能測試和其他工業空氣過濾研究的氣溶膠
功能及優點
+ 產生直徑0.1μm到10μm的高濃度氣溶膠顆粒
+ 產生氯化鉀（KCl）或其他氣溶膠
+ 符合已制定的ISO/TS 11155-1和ASHRAE 52.2測試規范的要求，以及建議的ISO 16890第2部分規范。
說明書
大顆粒氣溶膠發生器（氯化鉀發生器）
DLY-8108型
工作方式
通過噴嘴進行恒定液體供給
粒子粒徑大小
直徑0.1μm~to 10 μm
粒子濃度
1μm時約600粒/cm3，10μm時約10粒/cm3（等動力采樣用含30%濃度氯化鉀KCl）
粒子類型
氯化鉀 (KCl), 其它材料
液體供給速率
1.2 ml/min
操作要求
電 源：220V/AC
壓縮空氣：344kPa,141std.L/min(50psi,5scfm)
發生器機柱尺寸
高 142cm
外徑 30.5cm
底座 45 ×45cm
重量 25.5kg
控制柜尺寸
LxWxH 43×56×32cm
（未包含液體儲存裝置和支架）
重量 22kg
操作使用
大顆粒氣溶膠發生器（氯化鉀發生器）DLY-8108型，由兩部分組成：發生器機柱和控制箱。發生器柱包括噴嘴、干燥塔和電子空氣電離器（非放射性氣溶膠電荷中和器）?？刂葡浒粋€空氣壓力調節器，空氣過濾器、蠕動液體泵、加熱器、流量計和電離器電源。
DLY-8108型設計能夠長期穩定可靠運行。
開啟后，氣溶膠發生器從干燥塔頂部噴射氣溶膠。噴嘴易于維護，可從干燥塔頂部拆下進行清潔（一般情況下不需要拆卸維護）。干燥塔內的干燥筒體積能夠允許足夠的停留時間來干燥氣溶膠。從氣缸底部噴射的加熱和電離稀釋空氣有助于此過程。稀釋空氣將液滴充分混合并干燥，形成固體鹽顆粒，從發生器機柱底部的氣缸中排出。因為在流動管路中垂直沒有彎曲，氣溶膠可以以最小的粒子損耗被引導到測試管道中
| 非標定制大顆粒氣溶膠發生器（氯化鉀發生器）描述 類型DLY-8108 DLY-8108請說明電壓要求 |
規格如有更改，恕不另行通知。
